AT24C256C-SSHL-T

Цена 27.90 - 150.00 руб.

Описание AT24C256C-SSHL-T

The AT24C256C-SSHL-T is a 256kB I²C-compatible Serial EPROM IC with full memory write protect, supports up to eight d...

The AT24C256C-SSHL-T is a 256kB I²C-compatible Serial EPROM IC with full memory write protect, supports up to eight devices on a single 2-wire bus. Memory organized as 32.768 words x 8-bit. Optimized for applications where low-power and low-voltage operations are essential. The EEPROM operates from 1.7 to 5.5VCC.

• 2-wire Serial interface
• Schmitt trigger, filtered inputs for noise suppression
• Bidirectional data transfer protocol
• 400kHz (1.7V) and 1MHz (2.5, 2.7, 5.0V) compatibility
• Write protect pin for hardware protection
• 64-byte Page write mode - Partial page writes allowed
• Self-timed write cycle (5ms maximum)
• High reliability - 1.000.000 write cycles endurance
• Halogen-free

Серия	at24c
Тип памяти	eeprom
Объем памяти	256 kбит(32k x 8)
Максимальная тактовая частота (скорость)	1 мгц
Интерфейс	i2c2-wire serial
Напряжение питания	1.7…5.5В
Рабочая температура	-40…+85°C
Корпус	soic-8(3.9мм)
Вес	0.6г

В разработке.

Характеристики, параметры

Скачать файл

Наименование	Отгрузка, дней	Наличие, шт.	Цена, руб
AT24C256C-SSHL-T	4-5	4585	27.90
AT24C256C-SSHL-T	4-7	490	51.94
AT24C256C-SSHL-T	5-7	97	1000 41.93
AT24C256C-SSHL-T	5-7	2747	1000 41.93
AT24C256C-SSHL-T	1-2	51	1000 50.56
AT24C256C-SSHL-T	1-2	23	1000 50.56
AT24C256C-SSHL-T	4-6	2514	1000 47.29
AT24C256C-SSHL-T	4-8	600	1000 150.00
